Vetch Seed Cleaning Machine
Vetch (Vicia spp.) is an annual, winter-growing legume, used for Animal feed, a widely distributed scrambling herbaceous plant of the pea family, which is cultivated as a silage or fodder crop, of which there are species native to Europe, North America, South America, Asia and Africa.
Vetch seed cleaning machine function and application:
Vetch seed cleaning machine could clean and sieve kinds of grain and seed and agricultural byproducts,for example,corn,wheat ,rice,pulses and beans,millet ,sunflower seed,melon seed,cocoa bean, pepper, cumin, spice.
There is impurities,moldy vetch seed, bud seed damaged by insect or worms even stone in the vetch seeds. By using vetch seed cleaning machine,we could separate and remove those material from good material.It can clean light impurities through vertical air screen and the vibration sieve can clean big and small impurities.
The material can be classified into big, medium and small particles with different layers of sieves.It is widely used in seed processing and agricultural product processing industry.The vetch seeds cleaning machine not only clean up the vetch seeds,but also can clean up sunflower seed, beans, crops,wheat,sesame ,pepper seed ,soybean,green mung bean,oil seed ,vegetable seeds, rice ,millet etc.
Vetch seeds cleaning machine is consisted of machine frame,elevator system,seeds distributed box,air screen,vibration sieve ,dust collector,peas seed discharged outlet and control cabinet.
Vetch cleaning machine features:
· large capacity 5 ton per hour, 7.5 ton per hour,10 ton per hour.
· Zero broken peas seed bucket elevator
· Air blow adjustable for different materials and bran
· Closed air channel ,which is environmental
· Vibration sieve is high quality and easy cleaned by rubber ball.
· Whole machine is movable by equiped with tire.
· Brand electricity elements is used to guarantee peas seed cleaner work stable
· High performance with easy operation.
Specification of 5XZC-15 Grain Cleaning Machine:
|
Model No. |
Capacity(T/H) |
Power(KW) |
Weight(KG) |
Sieve Size |
Dimensions(MM) |
Remarks |
|
5XZC-5DH |
5 |
7.74 |
1.6 |
20001000 |
497019003100 |
with cyclone dust separator
|
|
5XZC-7.5D |
7.5 |
10.1 |
1.7 |
24001250 |
515021603500 |
|
|
5XZC-15 |
10 |
10.5 |
1.8 |
24001500 |
540023503500 |
